 Tool Operation Notices

1. Tool Selection
   • Our brand’s tools are designed for professional users, with different tools created for different materials.
   • They are mainly divided into five categories: particle board, MDF, solid wood, acrylic, and artificial stone.
   • Professional users must select the appropriate tool according to the material to achieve the best cutting performance and durability, and to avoid tool breakage caused by excessive pressure.
   • All tools are designed to rotate clockwise.
2. Balance Testing
   • Every tool undergoes balance testing upon completion to ensure there is no runout.
   • To further guarantee stability during use, please pay attention to selecting high-quality equipment and collets.
3. Collet Requirements
   • Always use a collet of the correct size.
   • If the collet is found to be out-of-round or worn, it will fail to properly clamp the tool.
   • Replace immediately with a standard collet to avoid dangerous situations such as vibration, tool ejection, or breakage during high-speed rotation.
4. Tool Shank Installation
   • Installation must comply with EU regulations.
   • For example, a shank diameter of 12.7 mm must be clamped to a depth of 24 mm to ensure the tool shank can withstand the required pressure.
5. Speed Settings
   • For tools with larger diameters, set the spindle speed according to the speed chart.
   • Feed the tool forward slowly and maintain a uniform feed rate.
   • Do not stop feeding during cutting, as this may damage the tool or workpiece.
   • Suggested router speeds

     Bit Diameter	Maximum Speed
     1” (25mm)	24,000 RPM
     1-1/4" - 2” (30 - 50mm)	18,000 RPM
     2-1/4” - 2-1/2” (55 - 65mm)	16,000 RPM
     3” - 3-1/2” (75 - 90mm)	12,000 RPM

6. Tool Replacement
   • When a tool becomes dull, replace it with a new one immediately.
   • Do not continue using a worn tool, as this may cause tool breakage and workplace accidents.
7. Blade Length Selection
   • Always select a cutting edge length greater than the workpiece depth.
   • For example, to mill a groove with a depth of 12.7 mm, choose a tool with a cutting edge length of 25.4 mm.
   • Avoid using tools with cutting edge lengths equal to or less than the workpiece depth.
8. Safety Precautions During Operation
   • Operators must wear safety glasses and use safety push handles.
   • When using tabletop machines, also install anti-kickback devices to prevent the workpiece from rebounding during high-speed cutting and causing accidents.
